Four-Wheel Suction Cleaning for Larger In-Ground Pools
- Complete Hayward The PoolCleaner 4-wheel suction-side cleaner
- Manufacturer model W3PVS40JST in white
- Designed for larger in-ground pools, commonly up to about 20 ft. x 40 ft.
- Approximately 40 ft. of sectional cleaner hose included
- Uses the pool's existing pump and filtration system for power
- Four-wheel drive, self-adjusting turbine vanes, programmed steering, and adjustable skirts
The Hayward W3PVS40JST The PoolCleaner 4-Wheel Suction Cleaner is a complete automatic suction-side cleaner designed for larger in-ground swimming pools. It connects to a dedicated suction line or compatible skimmer connection and uses the pool's existing circulation system for power, so a separate booster pump is not required.
The four-wheel version is built for longer and deeper pool layouts where additional traction and stability help the cleaner maintain coverage. Current product references list approximately 40 feet of hose with W3PVS40JST and describe the cleaner for larger in-ground pools, including applications up to about 20 feet by 40 feet when the available suction source and hose layout are appropriate.
Why the 4-Wheel PoolCleaner Works
Hayward's PoolCleaner platform uses self-adjusting turbine vanes that flex to maintain power across a range of flow conditions while allowing larger debris to pass through the turbine area. The cleaner's four-wheel drive works with its treaded tires to improve traction and obstacle maneuverability over common pool-floor features such as main drains and changes in surface contour.
An internal programmed steering system periodically reverses one wheel to redirect the cleaner. On the 4-wheel model, current product literature describes multiple programmed turns ranging from approximately 90 to 540 degrees, with straight travel between steering events. This helps the cleaner change direction without electronics, cords, or external programming.
Best For
- Larger in-ground swimming pools
- Pools with deeper sections or longer hose runs
- Concrete, gunite, vinyl, fiberglass, tile, and pebble pool surfaces
- Owners who want a suction cleaner powered by the existing pool system
- Replacing an older complete 4-wheel PoolCleaner with the current W3PVS40JST online model
Product Specifications
| Brand | Hayward |
|---|---|
| Product Line | The PoolCleaner |
| Manufacturer Part Number | W3PVS40JST |
| UPC / GTIN | 610377389921 |
| Cleaner Type | Suction-side automatic pool cleaner |
| Drive System | 4-wheel drive |
| Pool Type | In-ground |
| Recommended Application | Larger pools; commonly up to about 20 ft. x 40 ft. |
| Hose Length | Approximately 40 ft. |
| Power Source | Existing pool pump and filtration system |
| Booster Pump Required | No |
| Pool Surfaces | Common in-ground pool surfaces including concrete, gunite, vinyl, fiberglass, tile, and pebble |
| Color | White |
Coverage, Steering & Traction
The PoolCleaner uses an internal mechanical steering system rather than random freewheeling alone. The steering sequence changes the cleaner's direction at programmed intervals to help it cover both deep and shallow areas of the pool. Four-wheel drive adds stability for larger pools and longer travel distances, while raised tire tread helps the cleaner negotiate reasonable obstacles and uneven surfaces.
Patented adjustable skirts help maintain suction when one side of the cleaner passes over an obstacle. Actual wall-climbing and coverage depend on pool shape, surface condition, plumbing, available suction, hose setup, and cleaner maintenance, so performance should be evaluated as a complete system rather than by the cleaner alone.
Setup & Use
Before connecting the cleaner, make sure the pool circulation system is operating correctly and baskets and filter elements are clean. Connect the sectional hoses so the assembled hose reaches the farthest point of the pool with appropriate additional length, then connect the cleaner to the designated suction port or skimmer setup using the manufacturer's instructions. Remove air from the hose before final connection and adjust suction using the supplied or compatible flow-control components as directed by Hayward.
During routine service, inspect the tires, turbine vanes, skirts, steering components, hose sections, and suction path for wear or blockage. Tread wear indicators on the tires can help identify when replacement tires are due.
Buy with Confidence
Benchmark Pool Supply helps customers distinguish between Hayward's 2-wheel and 4-wheel PoolCleaner models and match the correct complete cleaner to pool size, depth, suction source, and hose requirements. For W3PVS40JST, confirm you need the white 4-wheel suction-side model for a larger in-ground pool.
Frequently Asked Questions
Is Hayward W3PVS40JST a suction-side or pressure-side cleaner?
W3PVS40JST is a suction-side cleaner. It connects to the pool's suction system and uses the existing pump and filter for power, so a booster pump is not required.
What size pool is the 4-wheel PoolCleaner designed for?
The 4-wheel model is intended for larger in-ground pools and is commonly listed for pools up to about 20 ft. x 40 ft., especially where a longer cleaner path or deeper pool favors the 4-wheel design.
How much hose comes with W3PVS40JST?
Current product listings specify approximately 40 feet of sectional cleaner hose with W3PVS40JST.
What is the advantage of the 4-wheel model over the 2-wheel PoolCleaner?
The 4-wheel version is intended for larger and generally deeper pools, providing additional traction and stability over longer travel distances. The 2-wheel version is typically used for smaller pools.
Does The PoolCleaner 4-wheel use a debris bag?
No. This is a suction-side cleaner, so collected debris travels through the suction line toward the pool's pump and filtration system rather than into an onboard cleaner bag.
